Jacuzzi J-495 User Manual

Page 17
J-400
North American J-415 Models (60 Hz)
Voltage: 240 VAC 240 VAC
Max. Current Draw: 25A 36A
Frequency: 60 Hz 60 Hz
Number of Wires: 3 3
Circuit Breaker (2-Pole): 30A* 50A**
*
In 30A conguration, the heater
will not operate while the jets pump
is running.
**
In 50A conguration, the heater will operate while the jets pump is
running. This is the factory setting.
 All Export 50 Hz Models: These models have two terminals
requiring 2 circuit breakers and only have one logic option available.
The breaker size for the J495 differs from all other J400 Models.
Export J-415/J-425/J-460/J-465/J-470/J-480 Models (50 Hz)
Main
Terminal Breaker*
Heater
Terminal Breaker**
Voltage: 230 VAC 230 VAC
Max. Current Draw: 16.6A 12A
Wattage 3.8 kW 2.6 kW
Frequency: 50 Hz 50 Hz
Number of Wires: 3 3
*
The main terminal breaker is solely for the pumps, circulation pump,
CLEARRAY, stereo option (if installed) and accessories.
**
The heater breaker is solely for the heater, to allow the heater to
operate
while both jet pumps are running.
Note: Two breakers needed see Figure E page 14.
Export J-495 Models (50 Hz)
Main
Terminal Breaker*
Heater
Terminal Breaker**
Voltage: 230 VAC 230 VAC
Max. Current Draw: 26.1A 23.5A
Wattage 6.0 kW 5.4 kW
Frequency: 50 Hz 50 Hz
Number of Wires: 3 3
*
The main terminal breaker is solely for the pumps, circulation pump,
CLEARRAY, stereo option (if installed) and accessories.
**
The heater breaker is solely for the heater, to allow the heater to
operate
while two jet pumps are running.
Note: Two breakers needed see Figure E page 14.
