JIF-2002 WEIGHING INDICATOR&CONTROLLER
19
STEP 6: System check will go to EEPRON 1 checking.
The screen will show EE-1. Please press ↵ key and the screen
will subsequently show a series blinking dots ……… indicating
system checking in process. If the screen shows PASS,
it means checking passed. If the screen shows FAIL,
it means system error.
STEP 7: System check will go to EEPRON 2 checking.
The screen will show EE-2. Please press ↵ key and the screen
will subsequently show a series blinking dots ……… indicating
system checking in process. If the screen shows PASS,
it means checking passed. If the screen shows FAIL,
it means system error.
STEP 8: System check will go to BCD checking.
The screen will show CODE 00.Please make SHORT-CIRCUIT
test on 9-Pin D shape Code Input on the rear panel. When
short-circuiting COM9 with other pins, the short-circuit pin will
show the accordance value on the screen. If not, there
suggests an error occurred.
STEP 9: System check will go to Input/Output checking.
When the screen show I - O , please enter ↵
key. Subsequently,
the screen will show INPUT 0 with the 0 blinking. Please make
SHORT-CIRCUIT test on 25-Pin D shape Code Input on the
rear panel. When short-circuiting COM17 or COM16 with pin
25∼pin18, the short-circuit pin will light up a specific LED on
the screen. If not, there suggests an error occurred.
※When short-circuiting COM17.COM16 with pin13∼pin16 , the
short-circuit pin will light up a specific LED on the front panel.
If two or more LED light up or turned off at the same time, there
suggests an error occurred.
