OPERATION AND MAINTENANCE MANUAL 12-2015
6
TYPE 7040
TYPE 7050
No. Part name Material Standard
1 Body Brass CuZn39Pb1Al-B PN-EN 1982: 2010
2 Cover Brass CuZn39Pb1Al-B PN-EN 1982: 2010
3 Float Stainless steel 1.4301 PN-EN 10088-1: 2014
4 Gasket Rubber EPDM/NBR PN-ISO1629: 2005
5 Nozzle Stainless steel 1.4301 PN-EN 10088-1: 2014
6 Lower lever Stainless steel 1.4021 PN-EN 10088-1: 2014
7 Top Lever Stainless steel 1.4021 PN-EN 10088-1: 2014
8 Bolt Stainless steel 1.4301 PN-EN 10088-1: 2014
9 Caulk ring Rubber EPDM/NBR PN-ISO1629: 2005
10 Screw Stainless steel PN-EN ISO 4017: 2011
No. Part name Material Standard
1 7010 valve Like in the table for 7010 Like in the table for 7010
2 7040 valve Like in the table for 7040 Like in the table for 7040
