OPERATION AND MAINTENANCE MANUAL
12-2015
9
TYPE 7050
DN H L D K l
x
n G
G
1
Masa
[kg]
50 / GW 2" 250 108 165 125 19x4 5/4" 8,5
80 280 128 200 160 19x8(4)* 2" 15,5
100 316 141 220 180 19x8 2" 19,5
150 355 173 285 240 23x8 2" 34,5
200 355 173 340 295 23x8(12)* 3" 35,6
[cal][mm]
3/4"
