BYPASS MODE SELECTION
Your pedal comes pre-set in true
bypass mode.
If you wish to change it to buffered
bypass mode so your trails will
fade out naturally after you have
disengaged the pedal:
y remove the power cable from
your pedal
y press and hold the TAP
footswitch
y insert the power cable
y release after you see the left LED
blink 3 times
To set your pedal back to true
bypass mode, repeat above steps.
The LED will now blink 2 times to
indicate successful true bypass
mode operation.
INTERNAL TRIMMERS LOCATION
1. Internal trimmer to set the trails'
fade out time
2. Internal trimmer to set the max.
number of repeats (multi-turn)
SPECIFICATIONS
y True or Buffered (Trails) Bypass
y Works with 9V DC adaptor
(tip-negative)
y Power consumption: 120 mA
y Dimensions (jacks, pots etc
included): 7.5 x 12 x 5.6 cm /
2.9 x 4.7 x 2.2 inches
y Weight: 280g / 0.6 lbs.
