10
3D Flight
3D-Flight
Throttle Curve Pitch
5 100 % hight +9° ~ +11°
3 50 %
1 100 % low -9° ~ -11°
Throttle Curve(3D Flight)
Stick position at high/Throttle 100%/Pitch+9º~+11º
Stick position at middle/Throttle 90%/Pitch 0º
Stick position at low/Throttle 100%/Pitch-9º~11º
Note:
• If the pitch angle is set too high, then the helicopter can not
move properly resulting in shorter flying time.
• If your set for a high rotor RPM, then a high pitch is
recommended..
• If unsure, it is always recommended to set a low pitch. The
result is that a higher rotor head RPM is achieved and the heli
copter will fly more stable.
Important:
When flying 3D, secure the canopy with an additional screw at
the bottom of the canopy. Otherwise it can come lose and dama-
ge the helicopter.
