RC4.6 remote control
5
Select
Enters Sound Adjustments
Volume
See page 4
Standby
Turns the keypad off
Local
Turns the keypad/system on
and selects local input if in-
stalled (avail. spring 2005)
All off
Turns system off
Mute
Mutes the keypad
EXT/CCTV
Turns the keypad/system
on and selects additional
source (e.a. CCTV) if in-
stalled
Volume adjustment
The LED blinks orange when adjusting volume up and down. When
reaching full volume the LED blinks red. When reaching minimum vol-
ume (Mute) the LED blinks green.
Sound adjustments
To enter Sound Adjustments push and hold Sound (4 sec.) to reach the
desired function. The LED blinks red once for Bass, twice for Treble, three
times for Balance and four times for Fader. If still held it will return to Bass
and cycle through again. Start to adjust the desired function within 2 sec.
or the system goes back to volume adjustment (LED green).
When adjusting Bass, Treble, Balance and Fader the LED blinks orange.
The led blinks red when reaching the top or bottom end and blinks
green at the mid point (no adjustment to sound).
If no adjustment is made the system will automatically go back to vol-
ume adjustment (LED green) after 2 sec.
Source
Turns the keypad/system
on and selects source 1 - 6
to be played
