Follow instructions for use
5.9. Memory
At the end of a measurement, this monitor automatically stores each result with date and time.
Each unit stores 120 sets measurements for 2 users, totally 240 sets（User A and B）.
Viewing the stored values
With the unit off, press the Memory button. The display first shows "A", then shows an average
of all measurements stored in the unit. Please note: Measurements for each user are
averaged and stored separately. Be certain that you are viewing the measurements for the
correct user. Pressing the Memory button again displays the previous value. To view a
particular stored memory, press and hold the Memory button to scroll to that stored reading.
5.10. Discontinuing a Measurement
If it is necessary to interrupt a blood pressure measurement for any reason (e.g the patient
feels unwell), the Start/Stop button can be pressed at any time. The device then immediately
lowers the cuff pressure automatically.
5.11. Battery Change Indicator
Batteries discharged– replacements required
When the batteries are discharged, the battery symbol will flash as soon as the instrument
is switched on. You cannot take any further measurements and must replace the batteries.
The battery compartment is located on the back side of the unit
a) Remove cover from the bottom plate, as illustrated below picture-06
b) Insert the batteries (2 x size AAA ). Always use AAA long life batteries or alkaline 1.5V
batteries.
c) The memory retains all values although date and time must be reset - the year number
therefore flashes automatically after the batteries are replaced.
