The following steps detail installation of the Color Splash LED light xture into an
existing pool. Read this section in its entirety prior to beginning any installation.
1. Disconnect the main electrical switch or circuit breaker and the switch which
operates the installed light.
2. Remove the existing light per the original manufacturer’s instructions. Place the
light xture on the deck.
3. Leaving the light xture on the deck, cut the light cord. Be sure to leave at least
six (6) inches of cord in order to connect it to the replacement light cord. Discard the
light xture.
4. Remove the existing cord by pulling it up out of the niche and onto the deck.
Failure to bring the pool and/or spa electrical system up to current code requirements
prior to light installation may create an electrical shock hazard resulting in death or
serious injury to users, installers, or others due to electrical shock, and may also cause
property damage.
WARNING! Pool or spa electrical system must meeting current
code requirements.
4" Min.
48" Min.
18" Min. Top of Lens
to Water Level
8" Min. Junction Box
or Low Voltage
Transformer to the
Max. Water Level of Pool
To Next Page
