Jands HP Series Technical Manual

Technical Data and Specifications 8-4
Revision 2 - 26 April, 2000 HP SERIES DIMMER TECHNICAL MANUAL
19 PIN SERIES-WIRED SOCAPEX OUTPUTS 1-6 (OUTPUTS 7-12)
CONNECTOR “A” CONNECTOR “B”
PIN No CONNECTION PIN No CONNECTION
1 ACTIVE 1 (7) 1 LINK 1 (7)
2 LINK 1 (7) 2 NEUTRAL 1 (7)
3 ACTIVE 2 (8) 3 LINK 2 (8)
4 LINK 2 (8) 4 NEUTRAL 2 (8)
5 ACTIVE 3 (9) 5 LINK 3 (9)
6 LINK 3 (9) 6 NEUTRAL 3 (9)
7 ACTIVE 4 (10) 7 LINK 4 (10)
8 LINK 4 (10) 8 NEUTRAL 4 (10)
9 ACTIVE 5 (11) 9 LINK 5 (11)
10 LINK 5 (11) 10 NEUTRAL 5 (11)
11 ACTIVE 6 (12) 11 LINK 6 (12)
12 LINK 6 (12) 12 NEUTRAL 6 (12)
13 EARTH 1 (7) 13 EARTH 1 (7)
14 EARTH 2 (8) 14 EARTH 2 (8)
15 EARTH 3 (9) 15 EARTH 3 (9)
16 EARTH 4 (10) 16 EARTH 4 (10)
17 EARTH 5 (11) 17 EARTH 5 (11)
18 EARTH 6 (12) 18 EARTH 6 (12)
19 NOT CONNECTED 19 NOT CONNECTED
10 PIN WIELAND
PIN No CONNECTION SOCKET “A” “B” “C”
1ACTIVE 159
2 NEUTRAL 1 5 9
3ACTIVE 2610
4 NEUTRAL 2 6 10
5ACTIVE 3711
6 NEUTRAL 3 7 11
7ACTIVE 4812
8 NEUTRAL 4 8 12
9 EARTH 1 5 9 + LOOP
10 EARTH 2 6 10 + LOOP
EARTH EARTH 3 7 11 + LOOPS +
4 8 12 + LOOPS
