Appendix C C -1
Revision 2 - 26 April, 2000 HP SERIES DIMMER TECHNICAL MANUAL
Appendix C Spare Parts
The following spare parts for HP Series dimmers are available from the JANDS Service
Department:
ITEM PART No.
Circuit breaker 11.5 amp (HP12-TR / HP12-SC) ZEB0200
Circuit breaker 25 amp (HP6-C) ZEB0250
Encoder knob ZZK1200
Encoder ZRP0350
CPU card complete YPC404
Front panel card complete (HP12-TR / HP12-SC) YPC402
Front panel card complete (HP6-C) YPC380
Output card complete (HP12-TR) YPC413
Output card complete (HP12-SC) YPC414
Output card complete (HP6-C) YPC408
Bi-colour LED ZDL0290
Red LED ZDL1050
Green LED ZDL1100
Alpha display ZDL3200
Front panel switch ZSW0500
3V Lithium battery CR20232 ZDC0050
30mA PTC Thermistor ZRX0300
Q6040J7 triac (HP12-TR) ZIX7100
S6035J SCR (HP12-SC) ZIX7250
S6065 SCR (HP6-C) ZIX7150
12V 80mm DC fan ZZA2010
Fan grille (old HP dimmers) ZZA2250
10 Amp Australian mains socket P415M ZZA5450
20 Amp Australian mains socket CAT38 ZZA5560
