Jands HP Series Technical Manual

Appendix D D -1
Revision 2 - 26 April, 2000 HP SERIES DIMMER TECHNICAL MANUAL
Appendix D Circuit Diagrams
FILENAME DESCRIPTION
HPTRPWR3 HP12-TR OUTPUT/POWER CARD
HPSCPWR6 HP12-SC OUTPUT/POWER CARD
HPSCHDF2 HP12-SC SCR FIRING CIRCUIT
DIMCPU8 HP DIMMER CPU CARD
HPCEFPN2 HP DIMMER FRONT PANEL CARD
HP6CPWR0 HP6 OUTPUT CARD
HPWMFPN2 HP WALL-MOUNT FRONT PANEL CARD
SUPERSEDED
12CHOP3 HP12 OUTPUT CARD
DIMFP5 HP12 FRONT PANEL CARD
DIMCPU4 HP12/6 CPU CARD
