Page 7
FloPro Series Pumps Installation and Operation Manual
Figure 1. Number of Suction Outlets Per Pump
At Least
3 Feet
Suction Outlet
(Main Drain)
Suction Outlet
(Main Drain)
No valves between
Tee and Main Drains
Listed/certified to the latest
published version of
ANSI/ASME A112.19.8
Anti-entrapment
Cover/Grate or Suction
Fitting, screw-fastened to
Main Drain Sump
Listed/certified to the latest
published version of
ANSI/ASME A112.19.8
Anti-entrapment
Cover/Grate or Suction
Fitting, screw-fastened to
Main Drain Sump
Valves OK between
pump and Tee
Pump
