SECTION 5.
Speed Adjustment with Booster
Pump
This section assumes that a booster pump is
properly plumbed and operating in the pool circulation
system. If not, you must install a booster pump before
proceeding (see instruction package with the booster
pump for installation). If you are uncertain whether the
pool has a booster pump, check with your local pool
professional.
5A. Speed Adjustment
1. From the kit, take the pressure gauge and thread
it into the test gauge case.
2. Locate where the Ray-Vac hose is connected to
the pool wall. Turn the quick disconnect fitting
and remove the hose from the pool wall fitting.
3. Unscrew the quick disconnect fitting from the end
of the cleaner hose. Remove the hose washer
from the quick disconnect fitting (see Fig. 14).
4. From the selection of five (5) speed adjustment
washers, select "C" and place it into the quick
disconnect fitting (see Fig. 4).
5. Insert the hose washer into the quick disconnect
fitting. The hose washer will hold the speed
adjustment washer in place.
6. Thread the quick disconnect fitting onto the end
of the filter screen case that has external threads
and thread this assembly onto the end of the
cleaner hose.
7. Insert quick disconnect fitting back into pool wall
fitting (see Fig. 5).
8. At the equipment pad turn on the filter pump. Wait
until the system is fully primed (pressure shows
on filter tank gauge).
Page 6
0-60 Pressure Gauge
Test Gauge Case
Speed Adjustment
Disk C
Speed Adjustment
Disks (A , B, D, & E)
Wall Fitting
Quick Disconnect
Fitting
Hose Washer
End of Ray-Vac Hose
Figure 14. Speed Adjustment
