JANE EXO BASIC - Adjusting the Harness Height; Unlock and Position Headrest; Reclining the Seat

36
EXO BASIC
Adjusting the height of the shoulder strap.
When the child is sitting correctly in the seat, check that shoulder straps are in the right position. They
should be slightly above the baby’s shoulders. EXO BASIC has 5 seat belt positions, on adjusting the
height the headrest moves. To change the height, follow the steps below:
4 Adjusting the harness
4a Pull the ring situated on the headrest (4),
this will unlock the headrest.
The EXO BASIC seat is reclined by using a lever
situated on the front part of the seat (16). It
has 4 positions.
5 Reclining the seat
4b Move the headrest (3) into the position sui-
table for the baby and release the ring. Move
the headrest until you hear the locking click.
Pull the headrest to check that it is secure.
To recline the seat, pull the lever (16) and slide
the seat to the required position.
