Jaquet MultiTasker T601 - Default Chapter; Table of Contents

Instruction Manual T601 JAQUET AG
Revision: 004 2/73
Contents
1 SAFETY NOTICE 6
2 PRODUCT FEATURES 7
3 SPECIFICATIONS 8
3.1 General 8
3.2 Inputs 9
3.2.1 Sensor Inputs 9
3.2.2 Analog Input 11
3.3 Binary Inputs 12
3.4 CAN Input 12
3.5 Outputs 13
3.5.1 Analog Outputs 13
3.5.2 Relays Outputs 14
3.5.3 Open Collector Outputs 14
3.6 Data communication 15
3.6.1 Ethernet 15
3.6.2 Connection to the Display 15
3.7 Environment 15
3.7.1 Climatic Conditions 15
3.7.2 Electromagnetic immunity 15
3.7.3 Other Standards 15
4 PRINCIPLE OF OPERATION 16
4.1 General 16
4.2 Machine factor 18
4.2.1 Measured 18
4.2.2 Calculated 18
4.2.3 Other physical parameters 18
4.3 Datalogger 19
4.3.1 Min- Max value registers 19
4.3.2 Event Recorder 19
4.3.3 Trip Datalogger 19
5 INSTALLATION 21
6 CONNECTIONS 22
6.1 Front view 22
6.1.1 Front view T601 22
6.1.2 Terminal A 23
6.1.3 Terminal B 25
6.2 Top View 27
6.2.1 Terminal C 27
