Adjus the Seat Poson and Angle
To change the angle and horizontal posion of the seat:
(1) Use a 6 mm Allen wrench to loosen the seat
adjustment bolt on the clamp posioned
immediately underneath the seatove the
rear wheel. Do not remove the bolt fully.
(2) Move the seat backward or forward and lt to
adjust the angle. A seat posion horizontal to
ground is desirable for most riders. Do not
exceed the limit markings on the seat rai
which show the minimum and maximum horizontal movement allowed.
(3)
While holding the seat in the desired posione a 6 mm Allen wrench to ghten
theseat angle adjustment bolt securely to the recommended torue value.
Prior to rst use, be sure to hten the seat clamp via the seat adjustment bolt
properly. A loose seat clamp or seatpost adjustment bolt can cause damage to the
bike, property, loss of control, a fall, serious injury, or death. Regularly check to
make sure that the seat clamp is properly htened.
1 2
The suspension fork can move up and down up to 80mm to
cushion bumps in the riding sur which can make riding
on a rough road or trail smoother and more comfortable.
Depending on a rider’s preference the suspension fork can
be locked out as a rigid forkwhich will typically yield higher
ncy while pedaling.
The lockout lever (1) located on the top of the right side of
the suspension focan be turned counterclockwise un
it stops to completely lock out the suspension fork’s travel.
To unlock the lockout leverturn the knob clock
wise un
stops. When the lockout lever is unlocked resist ance can
be adjusted by turning.
The preload adjustment knob (2) located on the top of the le side of the suspension
fork. To soen the ride subtract resistance by turning the preload adjustment knob
counterclockwis in the direcon of the small “-” on the knob. To make the suspension
s when going over bumpd resistance by turning the preload adjustment knob
clockwis in the direcon of the small “+” on the knob.
