DC FUSE PANEL LAYOUT
Below is a typical wiring layout. Your individual trailer may be different.
# Size Function
1 12.5 amp breaker Bedroom Slideout Motor
2 15 amp fuse Bathroom Lights & Vent
3 15 amp fuse Monitor Panel/Holding Tanks/Water Pump/Water Heater/Sink Lights
4 15 amp fuse Refrigerator/Furnace
5 15 amp fuse Bedroom Lights
6 15 amp fuse Propane Detector/TV Outlet
7 15 amp fuse Porch/Entry/Main Living Area Lights
8 15 amp fuse Bunk/Rear Ceiling/Trunk Lights
9 15 amp fuse Main Slideout Lights
10 15 amp fuse Option
11 15 amp fuse Option
12 20 amp breaker Main Slideout Motor
CIRCUIT BREAKERS
The following table provides generic circuit breaker alignment information. Your RV may not be
exactly the same as shown depending on model, floor plan and options.
Main 30 amp Main, Incoming Power to Unit
A 15 amp Microwave
B 15 amp Refrigerator/GFCI (Kitchen/Bath)
C 20 amp A/C
D 15 amp Utility/Converter
E 15 amp Water Heater
PROPANE CONSUMPTION CHART
The following chart provides an average propane consumption information.
Appliance
Average BTU
Consumption/Hr.
Kilojoules/Hr.
Water Heater 12,000 12,600
Refrigerator 1500 1585
Furnace 16,000 - 35,000 16,880 - 36,930
Range w/Oven 29,100 30,700
Slide-in Cooktop - 3 Burner 22,000 23,200
