SECTION 13 - EXTERIOR JAYCO TOWABLE
13-8 PNCFW
BIKE RACK /CARGO TRAY (IF SO EQUIPPED)
If your RV was ordered with the optional bike rack, do not use the rear bike rack
hitch for any other purpose (doing so will void the Towable Limited Warranty).
The optional rear bike rack hitch is not designed or intended to be used for towing.
Refer to the OEM operator’s manual. If you have any questions, consult your
dealer or Jayco Customer Service.
Fig. 13.2 Bike rack / cargo tray
safety locking pins.
Items that extend beyond the bike rack/cargo tray OR weigh over 250 lbs. (113.4
kg) will place undo strain on the RV. Some items may fall within the given weight
range, however, can still cause damage. Over time, excess weight added to the
tray will cause damage from the motion created while traveling. In addition, extra
weight behind the axle may reduce the hitch weight (leading to adverse handling
conditions from wind gusts and/or passing traffic).
Ensure the bike rack stand is securely locked in place at all times. When the bike
rack stand is not in use, it must be locked horizontal with the cargo tray frame.
Fig. 13.3 Bike rack stand
CAUTION
The bike rack / cargo tray must be secured to the RV frame by the safety
locking pins at all times. Damage caused by failure to set the locking pins or
improper loading or excessive loading voids the Towable Limited
Warrant
.
WARNING
If your RV is equipped with a roof ladder, do not leave items attached to it
while traveling. The ladder has a weight limit of 350# when using it to
access the roof. DO NOT exceed this weight limit.
