JAYCO TOWABLE SECTION 6 - ELECTRICALSYSTEM
6-5
5. Insert a new fuse of the same specified voltage, amperage rating and type in
the original location. Never use a higher rated replacement fuse.
The fuse panel label should be kept permanently affixed to your RV. The fuses will
not offer complete protection of the RV electrical system in the event of a power
surge or spike.
DC FUSE PANEL LAYOUT
Below is a typical wiring layout. Your individual RV may be different.
12-VOLT DC OUTLET (IF SO EQUIPPED)
There may be a 12-volt DC outlet (not applicable on all models) in your RV. When
the 12-volt DC outlet is used as a power source for an electric appliance, make
sure that the appliance operates on 12-volt DC power and that it consumes less
than 60 watts (5 amps) of 12-volt power. To prevent short circuits do not allow
metallic foreign matter to get into the 12-volt DC outlet.
REPLACING LIGHT BULBS
Before replacing a bulb, be sure the light is off. Do not touch the glass part of the
new bulb with your bare fingers. The skin oil left on the glass will evaporate when
the bulb gets hot, the vapor will condense on the reflector and it will dim the
surface.
Replacement light bulbs must be of the type, voltage and wattage listed on the
lamp fixture. Use of incorrectly sized bulbs can overload lam circuits and may
create a fire hazard by overheating the fixture.
# Size Function
1 — Open
2 15 amp fuse Bathroom Lights & Vent
3 15 amp fuse Pump/Monitor Panel/Range Hood/Sink Lights
4 15 amp fuse Refrigerator/Furnace
5 15 amp fuse Bedroom
6 15 amp fuse TV/Radio/Propane Detector
7 15 amp fuse Ceiling Lights
8 15 amp fuse Bunk Lights
9 15 amp fuse Slideout Lights
10 15 amp fuse Option
11 15 amp fuse Option
12 20 amp auto Slideout Motor
Interior Ceiling, Bunk Lights #921
Exterior Porch Light #922
Exterior Tail Light / Signal #3157
Exterior Clearance #194
WARNING
Replacement fuses must be of the same voltage, amperage rating and type.
Never use a higher rated replacement fuse; doing so may cause a fire by
overheatin
