Jayco Eagle 2006 - Bulbs; Fuses; DC Fuse Panel Layout; Television Cable

BULBS
I
WARNING: Replacement light bulbs must be of the type, voltage and
wattage listed on the lamp fixture. Use of incorrectly sized bulbs can
overload lamp circuits and may create a fire hazard by overheating the
fixture.
Interior
Square lights
921
Exterior:
Porch Light 912
Round Lights 912 Tail Light 1157
Turn Signal & Brake 1157
Clearance Light 194
FUSES
All fuses for the interior of the trailer and external porch lights are located in the fuse panel.
This panel is located near the converter.
I
WARNING: Do not replace circuit breakers or fuses with a higher
current rating than those originally supplied with the RV. Over fusing
can cause a fire hazard by overheating the electrical wiring.
DC FUSE PANEL LAYOUT
.
NOTE: Below is a typical wiring layout. Your individual trailer may be different.
# Size Function
1 12.5 amp breaker Bedroom Slideout Motor
2 15 amp fuse Bathroom Lights & Vent
3 15 amp fuse Monitor Panel/Holding Tanks/Water Pump/Water Heater/Kitchen Lights
4 15 amp fuse Refrigerator/Furnace
5 15 amp fuse Bedroom Lights
6 15 amp fuse Propane Detector/TV Outlet
7 15 amp fuse Porch/Entry/Main Living Area Lights
8 15 amp fuse Trunk/Hitch/Living Room Wall/Rear Overhead Cabinet/ Rear Ceiling Lights
9 15 amp fuse Main Slideout Lights
10 15 amp fuse Security Lights
11 15 amp fuse Option
12 20 amp breaker Main Slideout Motor
TELEVISION CABLE
The television coax cable is sized to accept satellite dish installations.
BRAKES
The electric brakes operate on 12 volt DC power from tow vehicle through blue and white
wires in the seven (7) wire harness and connector. More information on the brakes is found
in this manual and in manufacturer supplied information.
72 Eagle Conventional Travel Trailer and Fifth-Wheel Travel Trailer
Utilities & Systems
