will allow the jack to move out
of
its traveling position and
allow it
to
drop into place. Now extend the jack "foot" by
pushing
it
to the ground. More tension can
be
placed on the
jack feel by using the Iong jack handle supplied
in
each unit.
Be sure that
not
too much force is applied to the jack handie;
it
will
cause the holes in the jack legs to expand by breaking out
the dividers. One notch should
be
suficient.
excessive weight on these jacks as they are intended to
stabilize, not bear the weight
of
the camper.
To close, simply reverse the above procedure beginning with Step.
No.
11
and ending with Step
No.
1.
It is possible, due to an
unlevel campsite, that one corner may "hang
iip"
when you crank
down your unit. This is not
a
serious problem
and
is
due
to
bind in^
of the lifter arm.
To
solve this ~roblem. shake the carnDer
"
&
gently to move the roof back and forth, allowing it to come down.
Never force the hung
up
corner down
by
grabbing the roof and
applying your weight. This could damage the lifter am.
If
the roof
is persistent
in
sticking, crank up again and start over.
CAUTION:
If
stabilizer jacks
are down
while
roof
is
being
cranked
up
or down
it
is
very
possible
to
have
the
unit in
a
bind
causing
lifter
system
to
hang
1
UP
After roof is totally down and roof latches secured, before
removing crank, tighten cable system with a slight tension turning
as
you were raising camper. This will avoid cables becoming too
loose and beconling tangled with each other.
EASY
PATENT
#
345956
CRANK-UP
LI[EF%ER
SYSTEM
Jayco's
unique
raising
system has been thoroughly tested and
proven to
be
one of the best
on
the market and is relatively sirnpie
in
operation.
The
system
is
operated
by
a
manual winch. As the
lvinch turns. the main cable, which is connected to the four
secondary cables from each corner, is shortened.
As
the main
cable shortens,
it
pulls the secondary cables, forcing the flexibk
steel
core
to
be
pushed up~vard against the last tier of each
relcscopic arm. Because strong
force
can
be
achieved with litde
effort
through
a
pulley system,
the
roof can be lifted easily.
