CONVERTOR
Your interior Lights(s) and the
660
series heater (optional) will
operate from the 12-volt power source. If 110-volt
AC
is available,
the convertor
will
transform this current to 12-volt. This needs
to
be
switched manually. The
TRANS
position
is
used when the
110-volt current needs to be transformed to
12
volt. The
BATTERY
position is used when all current is to be received from
battery either in tow vehicle or optional auxiliary if used. The
OFF
position is used for traveling or storage.
These convertors
DO
NOT
have
a
built-in
battery
charger.
I
Convertors
are
available
in
'j"
series
as
an
option.
SATTERY
(OPTIONAL)
All
Jayco
units are pre-wired so that all interior 12-volt appliances
can
be operated
when
the tow vehicle and coach are connected
via
the wiring harness.
This
is
possible
onty
if
the dealer connects the
black
ivire
of
the
wire
harness
to
a
"hot"
supply.
An
auxiliary
battery
may
be installed
to
avoid discharging the
vehicle
battery.
Caution should
be
used
when drawing current from
your
tow
vehicle to
avoid
draining the battery to a point
that
the
tow
vehicle
will
not
start.
FUSES
For
the
"J"
series
an
inline
fuse
for
the
interior
circuit
is
installed,
located
in
the
left
front corner
of
the
camper
under
the
dinette
seat.
The
replacement
fuse
size
is
8A.
Other Jayco model
tent
campers have the interior circuit directed
through
the
convertor.
WARNING:
Do
not
repIace circuit breakers
or
fuses with those
of
a
bigher
current
rating
than
those
supplied
with
the
new
camper.
Over-fusing
can
cause
a
fire
hazard by overheating above
the
temperature rating
sf
the electrical
wiring.
