145
The “quick coupler” is directly connected to
the RV propane system. The “quick-coupler”
connection has a positive shut-o valve as re-
quired by code and standards.
1. Place the “quick coupler handle in the
OFF position and push back the sleeve.
The valve handle must be OFF to make the connection.
2. Insert the plug and release the sleeve
3. Push the plug until the sleeve snaps forward, locking the plug into the socket.
4. Turn the handle ON to allow propane to ow to the
drop in stove.
Your recreational vehicle may be equipped with an exterior refrigerator in the front storage
compartment, or in the outside kitchen (if so equipped). For information on use and safety,
refer to the manufacturer’s user guide.
The outside kitchen may include an LP fueled BBQ
grill. This grill is mounted in a pull out drawer. It has a
single burner control. It attaches to the LP tank using a
quick coupler connection as described above.
The drip pan attaches to tabs underneath the grill at
each end. A handle is mounted in the middle of the drip
pan to dump the contents. Refer to the grill user manual
for further information.
This grill is only available on certain RV models.
Outdoor cooking warning label
should not be removed from the RV.
A drip pan is included with the grill. The drip pan be used
underneath the grill to catch hot grease and liquids dripping from the grill
and to prevent injury.
