60
Direct access to ll the fresh water tank is typically located in
the sofa base. The exact location of the ll may vary depend-
ing on the model. Remove the cap for direct lling of the
water tank.
The fresh water tank can also be lled using the city tank ll
setting on the utility center.
To empty the fresh water tank, locate the drain valve under
the vehicle chassis close to the tank location. This will empty
the tank only. To drain the entire water system, the low point
drains must be used.
Most models have a factory installed water heater bypass
that enables you to avoid lling the water heater with RV
antifreeze. The 2-Valve Bypass is typically located in close
proximity to the water heater, and can be accessed through
the opening on top of the (driver side) sofa base. A and B
must be open to allow water into the water heater.
operation allows water to ow into the water
heater. Both hot and cold bypass valve handles should be
pointed toward the water heater connections.
operation diverts the ow of water around the water heater,
keeping water out of the water heater. Hot water bypass valve handle should point inline
with the (red) hot water outlet line. Cold water bypass valve handle should point inline with
the (blue) cold water inlet line.
Do not cap, block or modify the fresh water tank overow tubes in any
way. Enough water pressure can build up during the lling process to
damage the plumbing system if the overow tubes are obstructed.
Be careful not to overll the fresh water holding tank. It can pressurize
the tank, causing leakage and water damage and void the warranty. DO
NOT leave the tank unattended while lling.
