POWER ON/OFF BACKLIGHT BUTTONMUTE BUTTONSENSITIVITY
LEVEL
3
HOW TO OPERATE
1 TURN ON:
Press the ON/OFF button once to turn on and again to turn off.
NOTE: Hold button down for approximately 1 second to turn unit off.
2 WARM UP:
The detector automatically energizes the sensor conditioning it for use. During
the sensor conditioning cycle, the digital graph leak size indicator will gradually
increase and the detector will sound a slow “beep”. Warm up mode is usually
less than 20 seconds and is complete when the digital graph displays all 10 bars.
NOTE: When the detector has not been used for long periods,
conditioning may take slightly longer than usual.
3 READY:
The detector is ready to begin searching for leaks when the sensitivity setting
(HI, MED, or LOW) and the battery indicator are displayed on the LCD. The
audio “beep” increases in frequency.
LOW BATTERY INDICATOR
The battery indicator consists of the battery outline with 3 bars within the outline
and located in the upper center portion of the LCD display.
Battery level indication is the following:
Replace the 4 AA Alkaline batteries when the battery indicator shows no bars.
Follow battery installation instructions under MAINTENANCE.
Low Voltage
(Blinking)
Unit shut-down imminent
Quarter Voltage
Half Voltage
Full Voltage
CHANGE BATTERIES:
