EON518S Specifications
System Type: Self powered 18", bass-reflex design
Frequency Range (-10 dB): 36 Hz - 130 Hz
Frequency Response (±3 dB): 42 Hz - 100 Hz
Crossover Frequency: 120 Hz (HPF switchable on outputs)
System Power Rating: 500 W continuous, 1000 W peak
Distortion: Less than 0.1% at rated power
Maximum SPL: 129 dB
Signal Indicators:
Limit: Red LED indicates input overload condition
Signal: Green LED indicates signal present
Input Gain: - infinity to +4 dBu
Input Impedance: Nominal 20k Ohms (balanced)
Polarity: 0° or 180° phase shift
LF Driver:
1 x JBL 268G 460 mm (18”) Differential Drive
®
integrated
woofer with dual voice coils, 4 ohm load
Enclosure: 18 mm, plywood
Suspension / Mounting: 36 mm pole socket on top
Finish: DuraFlex™ finish
Grille: Powder coated perforated steel with acoustically transparent black screen backing.
Input Connectors:
Balanced XLRs with loop through (stereo) to balance XLR satellite outputs.
¼” Speaker level input.
XLR Pin Assignments: Pin 2 (+), Pin 3 (-), Pin 1 (GND)
AC input: 120 – 230v, 50/60 Hz
Dimensions (H x W x D): 617 x 569 x 652 mm (24.3 x 22.4 x 25.7 in)
Net Weight: 29.5 kg (65 lb)
Block Diagram
