System:
Frequency Range (-10 dB): 80Hz - 20kHz
Frequency Response (+/- 3 dB): 100Hz - 18kHz
Power Capacity
1
: 150 W
Sensitivity
2
: 87dB SPL, 1 W 1m (3.3 ft)
Maximum SPL
3
: 108dB continuous, 114dB peak
Directivity Factor (Q)
2
: 6.0
Directivity Index (DI): 7.8dB
Nominal Impedance: 4 ohms
Crossover Frequency: 4.2kHz
Overload Protection: Full-range SonicGuard™ power limiting to
protect network and transducers
Transducers:
LF Driver: 135mm (5.25 in) low frequency loudspeaker
HF Driver: 19mm (.75 in) polycarbonate dome tweeter
Enclosure:
Enclosure Material: Polypropylene Structural Foam
Finish: Black or White
Dimensions: 235mm x 159mm x 143mm
(9.25 in x 6.25 in x 5.6 in)
Net Weight (each): 1.8 kg (4 lbs)
Shipping Weight (pair): 4.6 kg (10 lbs)
Included Accessories: Mounting Bracket Assembly
1
IEC Standard, full bandwidth pink noise with 6 dB crest factor; 2 hour duration
2
Average 1 kHz to 10 kHz
3
Calculated based on power rating exclusive of power compression
JBL continually engages in research related to product improvement. Changes introduced into existing
products without notice are an expression of that philosophy.
8500 Balboa Boulevard
Northridge, CA 91329 USA
Visit us online at www.jblpro.com
© 2006 JBL Professional
P/N 363221-001
0706 REV B
Specifications

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the JBL Control 1 Pro and is the answer not in the manual?

JBL Control 1 Pro Specifications

General IconGeneral
Frequency Response80 Hz - 20 kHz
Impedance4 ohms
Sensitivity87 dB SPL, 1 W, 1 m
Crossover Frequency4.2 kHz
Dimensions235 mm x 159 mm x 143 mm
LF Driver135 mm (5.25 in)
HF Driver19mm (0.75")
Power Handling150 W (Continuous Program Power)
