JBL GTO752 - Electrical Parts List

GTO752 Electrical Parts List
Part Number Qty Reference Designator
MAIN PCB
Resistors
0702-34R7-02 Resistor 1/2W 4.7Ω ±5% 2 R25B R25C
0702-3220-02 Resistor 1/2W 22Ω ±5% 3 R46 R20 R19
0702-2221-02 Resistor 1/4W 220Ω ±5% 2 R20B R20C
0702-1220-02 Resistor 1/8W 22Ω ±5% 8 R16C R16B R15C R15B R14C R14B R13B R13C
0702-1470-02 Resistor 1/8W 47Ω ±5% 4 R4B R3C R4C R3B
0702-1101-02 Resistor 1/8W 100Ω ±5% 6 R38 R39 R40 R41 R12B R12C
0702-1821-02 Resistor 1/8W 820Ω ±5% 4 R24C R23C R24B R23B
0702-1102-02 Resistor 1/8W 1KΩ ±5% 16
R227 R226 R119A R17C R17B R2C R2B R1C R1B
R120A R111 R106 R28C R27B R27C R28B
0703-1332-03 Resistor 1/8W 3.3KΩ ±1% 2 R18C R18B
0702-1562-02 Resistor 1/8W 5.6KΩ ±5% 10
R9C R9B R8B R8C R118A R117A R116A R115A R19C
R19B
0702-1472-02 Resistor 1/8W 4.7KΩ ±5% 3 R2 R32 R37
0702-1103-02 Resistor 1/8W 10KΩ ±5% 22
R113A R108A R107A R104A R101A R100A R50 R36
R11C R11B R10C R10B R7C R7B R6C R6B R5C R5B
R110A R103A R1 R4D
0702-1473-02 Resistor 1/8W 47KΩ ±5% 3 R34 R106A R114A
0702-1563-02 Resistor 1/8W 56KΩ ±5% 6 R56B R56C R222 R221 R323 R320
0702-1104-02 Resistor 1/8W 100KΩ ±5% 5 R52 R55 R43 R217 R216
0702-1221-02 Resistor 1/8W 220Ω ±5% 2 R112A R105A
0702-1682-02 Resistor 1/8W 6.8KΩ ±5% 2 R102A R109A
0702-1273-02 Resistor 1/8W 27KΩ ±5% 2 R127 R128
0703-1301-03 Resistor 1/8W 300Ω ±1% 2 R231 R241
0702-1223-02 Resistor 1/8W 22KΩ ±5% 2 R101 R100
0703-1223-03 Resistor 1/8W 22KΩ ±1% 2 R204 R201
0703-1103-03 Resistor 1/8W 10KΩ ±1% 13
R316 R315 R314 R313 R312 R211 R209 R208 R207
R205 R203 R202 R200
0703-1472-03 Resistor 1/8W 4.7KΩ ±1% 4 R229 R224 R230 R210
0703-1562-03 Resistor 1/8W 5.6KΩ ±1% 2 R26C R26B
0705-50R1-06 Resistor 5W 0.1Ω*2 ±5% 26*5*18MM 2 R22C R22B
0704-6271-02 Resistor 2W 270Ω ±5% 2 R63 R62
1204-2030-01 potentiometer B20K KQ L=15 ±15% (INPUT LEVEL) 1 VR200
1204-5031-18 potentiometer
A50K R0971G2B W=5 KQ柄 L=15MM
T=7.5MM M=1MM (FREQ)
1 VR100A
1204-5021-06 potentiometer
B5K KQ L=15 ±10% 1,1" (BASS BOOST)
1 VR101
0703-2392-03 Resistor METAL MF 1/4W 3.9KΩ ±1% 1 R45
Capacitors
06D212274001 Cap electro 220UF/25V ±20% 8*16 105℃ 2 C216 C217
06D212266010 Cap electro 22uF/50V ±20% 5*11 105℃ 11
C15 C200 C201 C206 C211 C212 C11C C11B C12C
C12B C207
06D212264103 Cap electro 220uF/25V ±20% 8*12 105℃ 2 C42 C41
06D213375101 Cap electro 330UF/35V ±20% Ф8*14MM 105℃ 2 C32 C31
06D214765000 Cap electro 47UF/35V ±20% 5*11 105℃ 2 C55 C38
06D211074100 Cap electro 100uF/25V ±20% 6.3*11 105℃ 4 C37 C7C C7B C40
06D202264109 Cap electro 22uF/25V ±20% 5*12 105℃ 1 C18
06D211066109 Cap electro 10uF/50V ±20% 5*11 105℃ 2 C1C C1B
06D211056001 Cap electro 1UF/50V ±20% 5*11 105℃ 2 C9C C9B
06D212285106 Cap electro 2200UF/35V ±20% 16*26MM 105℃ 2 C58 C59
06D213384003 Cap electro 3300UF/25Vφ 18*26MM ±20% 105℃ 1 C17
06D321037200 Capacitor 103/100V ±5% 2 C7 C6
06D321047200 Capacitor 104/100V ±5% 6 2C 1C C8C C8B C10B C10C
06D321027200 Capacitor 102/100V ±5% 1 C29
06D321247000 Capacitor 124/100V ±5% 2 C131 C106
06D325637000 Capacitor 563/100V ±5% 2 C130 C107
Description
GTO752
8
