JBL GTR-601 SPARE PARTS LIS
T
Pos. No. P/N Description
1
ZS0201000069 FRONT PANEL
3
HG0201200217 Back-Side Panel 191.2*34.8*20.75 T=1.0 GTR-601
4
MK0201200412 Front-Side Panel 191.2*34.8*20.75
5
XG0201100205 BOTTOM PANEL 229.4*154.65*1.7 GTR-601
6
GD0301000160 2PIN FUSE COVER
15
SG0101000051 SPEAKER SOCKET 4P
16
SG0101000054 POWER SOCKET 3P
17
88LE03000372 GTR-601 LED Light PCBA
18
88AM03200743 GTR-601 AMP PCBA
L1
030503000001 Inductor ĭ28*12mm(ĭ1.0*6P)*2+1.0*1P K5A 13uH 7.5uH
M9,M10,M
11,M12,M
13,M14
050403000005 MOSFET DIP IRFB 38N20D TO-220
RCA1
120203000057 RCA JACK AV2-8.4-13AN(WR) White/Red 4P GTR-601
SW1
110103000060 Switch 4P3T Bar length G8 23.6*9.4*12mm GTR-601
SW1P,
SW2P
110603000024 DIP JUC-31F 80Ԩ൏3Ԩ H TO-220 58Ԩ൏4Ԩ GTR-601
SW2
110103000017 Switch SHC-22P-09 2P2T GTR-601
SW5B
221103000001 Relay 12A/120VAC 12VDC GTR-601
T1P
200403000204 Transformer D47 4.5:21.5:7.5:7.5 Hight27MM
U11
060103000026 IC IRS2092 SOIC16N SMD
U12
050703000019 Photocoupler TLP185 SO8 4P GTR-601
VR1,VR2,
VR4
010703000252 Potentiometer B20K ±10% H=11.3 L=7 GTR-601
140203000048 FUSE 35A 32V DIP UL GTR-601
CH0102000576 Gift Box L320*W234*H110mm GTR-601
WX0302000676
C t B L335*W237*H252 GTR 601
WX0302000676 Carton Box L335*W237*H252mm GTR-601
MP0501000076 Label on the bottom plate 127.6*47.6*0.35mm GTR-601
