WIND3
chargING
WATERPROOF
DUSTPROOF
IP67
1m
30 mins
IP67
1 2
BUTTONS
Bicycle
Mount
Tune Down (FM) /
Previous Track
(BT/TF)
Power On / Off
Press ≥1s
Source Switch
Tune Up (FM) /
Next Track
(BT/TF)
Source Switch to FM
mode
Volume Down
1
TUNE DOWN / TUNE UP:
Press 1x to tune down/up by step manually
Press 2x to tune to the previous/next
preset station
AUTO SCAN:
Long Press to Enter/ Exit Auto Scan
Auto Scan will automatically search for all
available stations and save to Presets
2
FM
1
2
Install the included
mounting bracket onto
bicycle handlebars.
Dock/undock the
speaker into the
mounting bracket
effortlessly
X1
bracket
X1
non-slip pads(big)
X1
QSG
X1
non-slip pads(small)
X1
plastic screw
X1
USB cable
WIND3
Volume Up
Play/Pause*
*long press to switch EQ between 'Sport' and 'Bass' mode
Answer/ Ignore incoming call: Short press/ Long press
End on-going call: Short press
TECH SPEC
Transducer: 43 mm x 47 mm / 1.5"
Output power: 5 W RMS
Frequency response: 110 Hz - 20 kHz
Signal-to-noise ratio: > 85 dB
Battery capacity: 1050 mAh
Battery charge time: 2.5 hours (5 V 1 A)
Music play time: up to 5 hours (dependent on volume level and audio content)
Bluetooth® version: 5.0
Bluetooth® profile: A2DP 1.3, AVRCP 1.6, HFP 1.7
Bluetooth® transmitter frequency range: 2400 MHz - 2483.5 MHz
Bluetooth® transmitter power: <5 dBm
(EIRP)
Bluetooth® transmitter modulation: GFSK, π/4 QPSK, 8DPSK
FM Tuning range: 87.5 MHz - 108 MHz (varies by countries)
Dimensions (W x H x D): 90 mm x 73.2 mm x 35.8 mm
Weight: 0.230 kg
Maximum operation temperature: 45 °C
