CONNECTION TIPS
Speakers and electronics
terminals have
corresponding (+) and (–)
terminals. It is important to
connect both speakers
identically: (+) on the
speaker to (+) on the
amplifier and (–) on the
speaker to (–) on the
amplifier. Wiring “out of
phase” results in thin
sound, weak bass and a
poor stereo image.
SPEAKER CONNECTIONS
– +– +
– +
Speaker Outputs
LEFT
RIGHT
– +
