SPEAKER PLACEMENT
MODEL:N28
5 – 6 ft.
MODELS:N38,ND310
As Front Speakers As Surround Speakers
OWNER’S GUIDE
PRODUCT LINE:
NORTHRIDGE SERIES
PRO SOUND COMES HOME
™
MODEL NUMBERS:
N28, N38, ND310
™
m
Proper placement of the
speakers is an important
step in obtaining the most
realistic soundstage
possible. These recom-
mendations are for the
optimum placement of the
loudspeakers. Use these
placement recommendations
as a guide. Slight variations
will not diminish your
listening pleasure.
All of the Northridge Series
loudspeakers referred to in
this guide are video-shielded
and can safely be placed
near a television.
N28, N38, ND310 OM 8/5/99 4:51 PM Page 1

Questions and Answers:

JBL N28 Specifications

General IconGeneral
Frequency Response55Hz - 20kHz
Sensitivity89dB
Impedance8 Ohms
Type2-way bookshelf speaker
Tweeter1" Titanium-laminate dome
Power Handling100W
Weight15 lbs

Summary

Speaker Placement

Placement for Models N38, ND310

Recommendations for optimum placement of N38 and ND310 loudspeakers for realistic soundstage.

Placement for Model N28

Guidance on placing N28 speakers as front or surround speakers.

Speaker Connections

Connection Tips

Importance of connecting speaker terminals (+/-) identically to the amplifier to avoid phase issues.

Troubleshooting

No Sound from Speakers

Checks for no sound from any or one speaker, including receiver status and balance control.

System Shuts Off at Volume

Troubleshooting steps for systems shutting off at higher volumes, checking wiring and impedance.

Low Bass Output

Ensuring correct polarity (+/-) for left and right speaker inputs for proper bass response.

No Sound from Center Speaker

Verifying center channel mode settings and connections for the center speaker.

Specifications
