JBL ProFlora u501 - Pressure Regulator Models and Functions

15
UK
return valve
• The JBL ProFlora m500 or m2000 (m range) rellable CO
2
bottles save resources.
• Easy-to-use JBL ProFlora u500 (u range) CO
2
disposable bottle
m503, m2003 only:
• CO
2
/ pH computer JBL ProFlora pH control touch with touch display and multilingual
user guidance in plain text.
Safe
• JBL ProFlora m500 or m2000 certied rellable compressed gas safety bottles with
overpressure protection
• Steady stand, no drilling required (m range)
• JBL ProFlora u500 (u range) certied disposable compressed gas safety bottle, free-
standing
• Pressure relief valve on the pressure regulator
• Bubble counter JBL ProFlora Count safe with integrated check valve to protect the
pressure regulator from owback water
• With hose screw connections to prevent hose from slipping
u502, m502 only:
• JBL ProFlora v002 solenoid valve powered by 12 V safety extra-low voltage
m503, m2003 only:
• JBL ProFlora pH control touch CO
2
/ pH computer powered by 12 V safety extra-low
voltage
4 Parts and names / contents
1) Safety storage bottles for CO
2
:
a: JBL ProFlora u500 (u range) disposable bottle, lled with 500 g CO
2
b: JBL ProFlora m500 rellable bottle with stand, lled with 500 g CO
2
(m range)
c: JBL ProFlora m2000 rellable bottle, lled with 2 kg CO
2
(m2003)
2) Pressure regulator
m001 for rellable bottles (m range)
u001 for disposable bottles (u range)
a: Connecting nut for rellable bottles, W21.8x1/14“ (m001).
b: Connecting thread for disposable bottles, M10x1 (u001)
c: Pressure gauge (display) for bottle pressure
d: Pressure gauge (display) for operating pressure
e: Connection (screw tting) for 4 / 6 mm CO
2
hose
f: Adjusting screw (needle valve) for amount of CO
2
g: Setting screw (Allen key) for operating pressure (under black cover)
h: Pressure relief valve
3) Solenoid valve mounted on pressure regulator (u502, m502, m503, m2003)
a: Valve body
b: Connection (screw tting) for 4 / 6 mm CO
2
hose
c: Universal power supply unit, 12 V DC secondary
4) JBL ProFlora Taifun CO
2
passive reactor
a: Lower part with screw connection
b: Lid for lower part (to prevent snails from entering)
c: Module:
u501, m501: 10 x
