Lock hole
Lock button
Speakon connector to the cable
PRX ONE-Install Adapter Bracket kit Assembly & Bracket Installation Guide – Page 7
8)
Install Adapter to Array
Insert Array adapter to the Bottom array. Once you hear a click, this indicates a secure installation
Bottom Array
Top Array
Array Adapter
For safty cable
installation
For safty cable
installation
