S-CENTER
Description: 3-Way dual 5" center
Maximum Recommended
Amplifier Power*: 150W
Nominal Impedance: 8 Ohms
Sensitivity (2.83V/1m): 91dB
Frequency Response (–3dB): 80Hz – 20kHz
Crossover Frequencies: 800, 3200Hz
High-Frequency Transducer: 1" Pure-titanium dome, with rubber surround,
shielded; Elliptical Oblate Spheroidal™ (EOS)
waveguide
Midrange Transducer: 4" PolyPlas™ (polymer-coated cellulose fiber)
cone, rubber surround, shielded; Linear Field
Proximity™ (LFP) bezel
Low-Frequency Transducer(s) : 5-1/2" PolyPlas™ (polymer-coated cellulose fiber)
cone, rubber surround, SFG™, magnetic shorting
rings, high-temp oversized Kapton
®
voice coil,
HeatScape™ motor structure, cast-aluminum
baskets, shielded
Baffles: Low Diffraction, IsoPower™
Port: FreeFlow™ flared
Network: Straight-Line Signal Path™ (SSP)
Terminals: All-metal, gold-plated 5-way binding posts
Dimensions (H x W x D): 7-7/8" x 20-1/2" x 9"
200mm x 521mm x 229mm
Weight: 15lbs, 6.8kgs
SPECIFICATIONS
Declaration of Conformity
We, JBL Europe A/S
Kongevejen 194B
DK-3460 Birkerød
DENMARK
declare in own responsibility, that the loudspeaker
described in this owner’s manual is in compliance with
technical standards:
EN 50081-1:1992
EN 50082-1:1992
Steen Michaelsen
JBL Europe A/S
Birkerød. DENMARK. 8/99
*The maximum recommended amplifier power rating will
ensure proper system headroom to allow for occasional
peaks. We do not recommend sustained operation at these
maximum power levels.
Occasional refinements may be made to existing products
without notice but will always meet or exceed original
specifications unless otherwise stated.
