JBL SOURCE User Manual

14
Dolby Pro-Logic
Ò
Surround Processor/CD Player/Tuner SOURCE
MECHANICAL PARTS LIST
Ref. # Part Number Description Qty
1 BPT0011-AG1 TOP CABINET 1
2 BPH0018-001 DOOR HOLDER 1
3 BPG1017-001 DOOR LEG 1
4 BPN0051-002 DISC WINDOW 1
5 BPD1016-AG1 CD DOOR 1
6 DSF0002-001 DOOR SHAFT 2
7 GSE0131-001 DOOR BRACKET (LEFT) 1
8 MSV0002-001 LEVER SWITCH 1
9 BPN0052-001 POWER LENS 1
10 BPC0015-001 KNOB CAP 1
11 BPK6020-000 POWER KNOB 1
12 APE0153-031 POWER LED PCB ASSEMBLY 1
13 GSE0130-001 MOTOR BRACKET 1 1
14 FMD0004-001 MOTOR 1
15 BPG1029-001 GEAR F 1
16 DSF0001-001 SHAFT GEAR 2 1
17 BPG1027-001 GEAR D 3
18 BPH0027-001 HOLDER (GEAR) 1
19 BPG1026-001 GEAR C 1
20 HWC4016-302 WASHER OD4.0xID1.6xT0.2 mm MYLAR 3
21 DSF0005-001 SHAFT GEAR 1 1
22 BPG1028-001 GEAR E 1
23 GSE0130-001 MOTOR BRACKET 1
24 DSF0003-001 STUD (GEAR) 1
25 BPG1030-001 GEAR G 1
26 BPG1025-001 GEAR B 1
27 BPG1024-001 GEAR A 1
28 DSU0018-002 SPRING GEAR 800g 1
29 GSE0129-001 DOOR BRKT RIGHT 1
30 BRW0001-001 MOTOR BELT 1
31 DSF0006-001 INSERT 2
32 BRF0012-001 DOOR CUSHION 2
33 BPK4019-000 OPEN/CLOSE KNOB 1
34 BPK2032-000 AM/FM KNOB 1
35 BPK2033-000 FUNCTION. KNOB 1
36 BPK1046-001 SKIP KNOB 1
37 APE0151-021 PHONE JACK PCB ASSEMBLY 1
38 BPK5030-AG0 VOLUME KNOB 1
39 APE0152-021 VR PCB ASSEMBLY 1
40 BPH0021-001 CD HOLDER 1
41 DSU0016-001 CD SPRING LEFT 1
42 DSU0015-001 CD SPRING RIGHT 1
43 BRF0009-001 CD CUSHION WHITE 2
44 BRF0009-002 CD CUSHION BLACK 1
45 WCD0010-001 CD PLAYER CD93V4BF 1
46 APE0152-011 CD DECODER PCB ASSEMBLY 1
Ref. # Part Number Description Qty
47 APE0154-001 PRO-LOGIC PCB ASSEMBLY 1
48 APE0151-011 CONTROL PCB ASSEMBLY 1
49 BPB0010-AGI BOTTOM CAB 1
50 APE0153-001 MAIN PCB ASSEMBLY 1
51 GSE0135-001 MAIN BRACKET BACK RIGHT 1
52 GSE0136-001 MAIN BRACKET BACK LEFT 1
53 GSE0133-001 MAIN BRACKET FRONT LEFT 1
54 GSE0134-001 MAIN BRACKET FRONT RIGHT 1
55 BPH0020-AG0 JACK PLATE 1
56 BPN0032-001 NAME PLATE FOR ESC550 1
BPN0032-002 NAME PLATE FOR ESC350 1
57 BPC0012-001 CABINET CAP 2
58 BRF0008-001 FOOT 4
59 BPN0054-001 SENSOR WINDOW 1
60 BNP0032-001 DISPLAY SHEET 1
61 BPN0053-002 DISPLAY WINDOW 1
62 BPH0019-AG0 WALL BRACKET 1
63 GSE0143-001 BRACKET DOOR 1 1
64 DSS0010-001 SPACER SUPPORT 4
65 GTN0026-001 SHIELD PLATE 1
MAIN PCB TO BOTTOM CABINET
66 CLJ0007-001 JBL LOGO PLATE 1
S1 H101501-105 SCREW T2.6xL5.0mm TAPPING 3
HEAD PHONE TO TOP
S2 H101508-306 SCREW T2.6xL6.0 mm FLAT HEAD 4
DOOR TO HOLDER
S3 H060301-104 SCREW M3. 0xL4 .0xP0. 5 mm 2
NICKEL DOOR BRACKET
S4 H060001-106 SCREW M1.7xL6.0 mm NICKEL SLIDE 2
SW-2
S5 H101001-110 ”SCREW T3.0xL10.0 mm NICKEL 21
AM/FM KNOB TO TOP-2 BRKT TO
BOTTOM-2, FUNCTION KNOB TO
TOP-3 SKIP KNOB TO TOP-2,
FUNCTION PCB TO TOP-1, CD PCB TO
TOP-4, OPEN/CLOSE KNOB TO TOP-1,
CD HOLDER TO TOP-4, POWER KNOB
TO TOP-1, POWER PCB-1"
S6 H060101-304 SCREW M2.0xP0.4xL4.0 mm’ BLACK 2
S7 H101501-508 SCREW T2.6xP1.058xL8.0 mm PAN 2
HEAD ZINC MOTOR BRACKET TO TOP
S8 H060201-116 SCREW M2.6xP0.45xL16.0 mm NICKEL 2
MOTOR CASE
S9 H100301-306 SCREW TAPPING 3.0 x 6 BLACK MAIN 2
PCB TO BRACKET
S10 H101001-108 “SCREW T3.0x1.27P-2RHxL8 mm NICKEL 5
(PAN HEAD) DOOR BRACKET TO TOP-3,
BRACKET TO BOTTOM-2
S11 H101001-310 “SCREW T3.0xL10.0 mm PAN HEAD 9
BLACK TOP TO BOTTOM-5, JACK TO
HOLDER-4"
S12 H120301-308 SCREW M3x0.5Px8 mm BLACK DIN 3
JACK TO HOLDER-3
