JBL SYNTHESIS S3-SPP User Manual

2.3 System Installation
The S3-SPP is designed for connection in
the audio signal path, between the
surround processor and the power ampli-
fiers. Refer to the following diagram for
a typical system layout:
POWER
SIG GND
LIFT
CHASSIS
GND
750 mA
CLASS 2 EQUIPMENT
MADE IN U.S.A.
S3-SPP
JBL INCORPORATED
NORTHRIDGE, CA
INPUTS
OUTPUTS
LEFT FRONT CENTER RIGHT FRONT SUBWOOFER
PARALLEL
N/C
SCREEN BOOST & HF CONTOUR
SCREEN BOOST
ON
OFF
AUTO
PIN 5: SCREEN BOOST/HF CONTOUR +5V=ON
PINS 1&2: RELAY COMMAN
SIGNAL PROCESSING PACKAGE
SDP-1 SURROUND PROCESSOR
ADDITIONAL CONNECTIONS (not shown above)
1. 5 pin din cable from SDP-1 (CONTROL OPTION) to S650 (IN).
2. 5 pin din cable from S650 (X-OVER) to S3-SPP
(SCREEN BOOST AND H.F. CONTOUR).
3. 5 pin din cable from S650 (OUT) to S400 (IN).
4. 5 pin din cable from S650 (SPKR 1) to Left Speaker (MODE CONTROL) — Home Media System Only.
5. 5 pin din cable from S650 (SPKR 2) to Right Speaker (MODE CONTROL) — Home Media System Only.
S650 POWER AMPLIFIER S400 POWER AMPLIFIER
S3-SPP
(160mA MAX)
OUT
VIDEO
REAR SIDE FRONT
L
L
4
1
IN
3
2
2
3
1
R
R
L
R
CENTER
INPUTS
TAPE OUT
OUTPUTS
VIDEO
SUB
WOOFER
CD
LD
CH 1 CH 2 CH 3 CH 4 CH 5 CH 2CH 1
(FIGURE 1)
2.0
SYNTHESIS THREE
SIGNAL PROCESSING
PACKAGE (S3-SPP)
5
