SDEC-4000 WITH BI-AMPLIFIED FRONT SPEAKERS
This configuration requires the selection of bi-amplified operation, as noted on page 11.
SSDDEECC--44000000XX OOuuttppuuttss ttoo AAmmpplliiffiieerrss
SS44000000IICC
NNuummbbeerr CChhaannnneell SSDDEECC--44000000XX AAmmpplliiffiieerr IInnppuutt CChhaannnneell
9 LEFT FRONT-LOW A1 S5160 #1 CH1
10 LEFT FRONT-HI A2 S5160 #1 CH2
11 RIGHT FRONT-LOW A3 S5160 #1 CH3
12 RIGHT FRONT-HI A4 S5160 #1 CH4
13 CENTER FRONT-LOW B1 S5160 #2 CH1
14 CENTER FRONT-HI B2 S5160 #2 CH2
15 LEFT SIDE 1 B3 S5160 #2 CH3
16 LEFT SIDE 2 B4 optional –
N/C C1 – –
N/C C2 – –
17 RIGHT SIDE 1 C3 S5160 #2 CH4
18 RIGHT SIDE 2 C4 optional –
N/C D1 – –
N/C D2 – –
19 LEFT REAR D3 S5160 #1 CH5
20 RIGHT REAR D4 S5160 #2 CH5
SSuurrrroouunndd PPrroocceessssoorr ttoo SSDDEECC--44000000PP IInnppuuttss
SS44000000IICC
NNuummbbeerr CChhaannnneell SSDDEECC--44000000PP
1 FRONT LEFT A1
2 FRONT RIGHT A2
3 CENTER FRONT A3
4 LEFT SIDE A4
5 RIGHT SIDE B1
6 LEFT REAR B2
7 RIGHT REAR B3
8 SUBWOOFER B4
(Mono Sub L)
N/C C1
N/C C2
N/C C3
N/C C4
9
INPUT/OUTPUT ASSIGNMENTS
SSDDEECC--44000000PP OOuuttppuuttss ttoo AAmmpplliiffiieerrss
NNuummbbeerr CChhaannnneell SSDDEECC--44000000PP
21 SUBWOOFER 1 D1 S800 #1 CH1 (bridged)
22 SUBWOOFER 2 D2 S800 #2 CH1 (bridged)
23 SUBWOOFER 3 D3 S800 #3 (optional) CH1 (bridged)
24 SUBWOOFER 4 D4 S800 #4 (optional) CH1 (bridged)
Input/Output Assignments
