2-2
Basic Operation
JBL
FRONT PANEL
1
2 4 5
6
7
8
9
10
11
12
3
1
Red LED
Blue LED
Amber LED
IR RECEIVER
(Standby) toggles the unit between on and standby. When
the unit is on, pressing this button places the unit into standby
and lights the red LED on this button. Power is still supplied to
the unit when it is in standby. When the unit is in standby,
pressing this button activates all zones that were active in the
previous operating session.
