CUSTOM SETUP
FRONT L/R 80Hz
CENTER 80Hz
SIDE L/R 80Hz
REAR L/R 80Hz
SUB L/R MONO
SUB XOVER 80Hz
LFE OFF
3-21
The SETUP Menu
SDP-40
SIDE L/R SPEAKERS
FULL
30Hz
40Hz
50Hz
60Hz
70Hz
80Hz
THX 80Hz
90Hz
100Hz
110Hz
120Hz
NONE
REAR L/R (FULL, 30Hz to 120Hz, THX 80Hz, NONE)
The REAR L/R parameter sets the crossover setting for the MAIN
AUDIO OUTPUTS labelled REAR L/R. When set to FULL, the unit
sends a full-range audio signal to the REAR L/R outputs. When set
to a numerical crossover setting, the unit activates a crossover at
the selected frequency. Choose the setting closest to the low-
frequency rating of the rear left and right speakers. See pages 3-18
and 3-19 for more information about crossover settings.
When set to NONE, the unit redirects rear channel signals to the
SIDE L/R outputs. When both the SIDE L/R and REAR L/R
parameters are set to NONE, the unit redirects surround channel
signals to the FRONT L/R outputs.
SIDE L/R (FULL, 30Hz to120Hz, THX 80Hz, NONE)
The SIDE L/R parameter sets the crossover setting for the MAIN
AUDIO OUTPUTS labelled SIDE L/R. When set to FULL, the unit
sends a full-range audio signal to the SIDE L/R outputs. When set
to a numerical crossover setting, the unit activates a crossover at
the selected frequency. Choose the setting closest to the low-
frequency rating of the side left and right speakers. See pages 3-18
and 3-19 for more information about crossover settings.
When set to NONE, the unit redirects side channel signals to the
REAR L/R outputs. When both the SIDE L/R and REAR L/R
parameters are set to NONE, the unit redirects surround channel
signals to the FRONT L/R outputs.
SETUP
INPUTS
SPEAKERS
REAR PANEL CONFIG
DISPLAYS
VOLUME CONTROLS
TRIGGERS
LOCK OPTIONS
MAIN MENU
MODE ADJUST
AUDIO CONTROLS
SETUP
REAR L/R SPEAKERS
FULL
30Hz
40Hz
50Hz
60Hz
70Hz
80Hz
THX 80Hz
90Hz
100Hz
110Hz
120Hz
NONE
SPEAKER SETUP
CUSTOM SETUP
SYNTHESIS 7CH SETUP
SPEAKER DISTANCES
LEVELS CALIBRATION
