JBM 54291 - Parts List; Exploded View Parts Diagram (1.1)

· 8 ·
REF.54291
No. Name Quantity
1 High-pressure manometer,35bar 2
2 Printer 1
3 Weighing sensor 1
4 Hexagonal screws 8
5 Condenser assembly 1
6 Compressor components (220V 50/60Hz) 1
7 Control module assembly 1
8 The ship type switch 1
9 Power outlet 1
10 Low pressure gauge15bar 1
PARTS LIST (EXPLODED VIEW)
1.1 Parts diagram
