A: the excavator bucket arm lock
Push up to unlock the bucket arm, pull the bucket arm back and then push
down the lock can fix the bucket arm.
27
28
8. Digging bucket operation instruction
1
1. Pull back the retractable spear firstly.
2. Pull down the support wheel.
3. When not using the bucket, please withdraw the support wheel: lift the wheel
up and push the retractable spear back to the initial position.
!
！
WARNING
RISK OF TIPPING OVER
Before use, the anti-tip wheel must be
rotated to the anti-tip position,
otherwise it may cause injury to the
user or cause other damage.
Remove the foam from the excavator bucket seat support wheel.
