15 - Engine
18 - Engine Belt
03 - Drive Belt
15 - 79 9813/2700-2 15 - 79
03 - Drive Belt
Introduction .................................................... 15-79
Health and Safety .......................................... 15-80
Component Identification ............................... 15-80
Check (Condition) .......................................... 15-81
Adjust ............................................................ 15-81
Remove and Install ....................................... 15-83
Introduction
Original Belt Configuration
The alternator adjusting lever makes sure that the
front end accessory drive belt (FEAD) is kept at the
correct tension.
Figure 143.
B
A
A Alternator
B Adjusting lever
Alternate Belt Configuration
A tensioning screw, which adjusts the tightening
pulley travel, makes sure that the front end accessory
drive belt (FEAD) is kept at the correct tension.
Figure 144.
A
B
A Tightening pulley
B Tensioning screw
