jcb 100 C-1 User Manual

15 - Engine
21 - Oil Filter
00 - General
15 - 89 9813/2700-2 15 - 89
Component Identification
Figure 158.
A
B
A Oil Filter
B Element
Figure 159.
C
D
B
A
A Cartridge holder cover
B Oil filter support
C Oil returning into the circuit
D Oil returning to the crankcase
Figure 160.
H
E
A
B
G
F
A Cartridge holder cover
B Oil filter support
E Oil filter cartridge
F Outgoing fitting from filter
G Water/oil heat exchanger
H Crankcase
