01 - Machine
09 - Description
12 - Main Component Locations
01 - 19 9813/5350-2 01 - 19
12 - Main Component Locations
Introduction
(For: 10TFT, 9TFT)
Figure 3.
E
F
A
B
D
G
C
A ROPS (Roll-Over Protective Structure) B Seat
C Engine compartment cover D Tyres
E Steps F Skip
G Hand rails
