01 - Machine
09 - Description
12 - Main Component Locations
01 - 21 9813/7900-2 01 - 21
12 - Main Component Locations
Introduction
Figure 4.
A
C
G
E
F
D
B
A Cab/canopy (contains the operator station) B Boom (part of the excavator arm)
C Dipper (part of the excavator arm) D Bucket
E Dozer blade F Undercarriage
G Upper structure
