jcb 210 Series

16 Please see operator manual for full details.
Pedals and controls
2
1
A
B
1
2
Track levers
TAB boom controls (option)
Fig 14
Fig 15
A Left track lever
B Right track lever
C Right track pedal
D Left travel pedal
E Footrests
A Pedal
B Ram
1 Heel end of pedal: Extend the ram
2 To end of the pedal: Retract the ram
A
A
D
B
C
