01 - Machine
09 - Description
15 - Service Point Locations
01 - 24 9813/7850-2 01 - 24
Hydraulic Compartment
Figure 6.
A
B
C
D
A Air intake B Hydraulic oil filler cap
C Hydraulic oil level indicator D Radiator
