Main Component Locations
The illustration shows a typical machine model. Your machine may look different from the one shown.
Figure 5.
A
D
J
E
C
G
F
H
B
A ROPS/FOPS cab B Fuel tank filler point
C Lift arm/boom D Front working lights
E Quickhitch F Rubber tracks
G Engine top cover H Wheels/tyres
J Exhaust
